ADI Engineering Pronghorn Metro SBC
Talk0
1,179pages on
this wiki
this wiki
Your here: Home / Network / Hardware Specific / ADI Engineering / Pronghorn Metro SBC
 |
This article is a stub. Please help InfoDepot Wiki by expanding it, adding pictures, and improving existing text.
|
| ADI Engineering Pronghorn Metro SBC | |
|---|---|
 | |
|
Homepage | |
|
Wikipedia |
? |
|
dd-wrt |
? |
|
OpenWRT |
? |
|
Tomato |
? |
|
TomatoUSB |
Not Supported |
|
Gargoyle |
? |
Contents |
NOTE: Activation Required.
NOTE: During configuration or flashing a device, the only that should be hooked to the device is the computer and power.
Specs
Edit
This section is in need of cleanup!
Platform
Serial Num. = ?
FCC ID = ?
CPU Type = Xscale IXP425
MIPS Rev = ?
CPU Speed = 533MHz
Bus = ?
Flash Type = ?
Flash Chip = ?
Flash Size = 16MB
Max Firmware Size = ?
RAM Size = 64MB
RAM Chip = ?
nvram Size = ?
Switch = ?
Port-based vlan = ?
802.1q vlan = ?
Ethernet Port Count = 1-LAN 1-WAN
Wired Standard = IEEE 802.3?
boot_wait = ?
bootloader = ?
Flash Card Socket/Type = Yes/Compact Flash
SD/MMC Mod Support = No
MiniPCI slots = 4
PoE = Yes
Power = 17-30 & 36-60
Color of LEDs = ?
Size = ?
USB = No
Serial Port = Yes
JTAG Port = ?
Supported by TJTAG/Version = ?
Supported by dd-wrt as of = v24 pronghorn-SBC - Build 9917
dd-wrt K2.4 Support = ?
dd-wrt K2.6 Support = ?
Special Features = Compact Flash socket, hardware watchdog,
temperature and voltage sensor
Radio
Wireless Radio = depends on card
Radio
Wireless Radio = depends on card
Radio
Wireless Radio = depends on card
Radio
Wireless Radio = depends on card
