Platform

Serial Num. = ?
FCC ID = ?
CPU Type = Geode SC1100
MIPS Rev = ?
CPU Speed = 266MHz
Bus = ?
Flash Type = ?
Flash Chip = ?
Flash Size = 2 Mbit Flash BIOS on board
Max Firmware Size = ?
RAM Size = 1 SoDimm up to 256MB
RAM Chip = Depends on SoDimm
nvram Size = ?
Switch = NSC DP83816
Port-based vlan = ?
802.1q vlan = ?
Ethernet Port Count = 2-10/100-LAN
Wired Standard = IEEE 802.3/3u
boot_wait = N/A
bootloader = ?
Flash Card Socket/Type = Yes
SD/MMC Mod Support = ?
MiniPCI slots = no, but PCMCIA & pci card
PoE = 802.3af
Power = 20-56
Color of LEDs = ?
Size = ?
USB = One port with USB 1.1
Serial Port = Yes
JTAG Port = ?
Supported by TJTAG/Version = ?
Supported by dd-wrt as of = x86 version, write image via physdiskwrite
                            to cf-card
dd-wrt K2.4 Support = ?
dd-wrt K2.6 Support = ?
Special Features = ide port, hardware watchdog, temp. sensor

Radio

Wireless Radio = depends on card

 This section is in need of cleanup!

 This section is in need of cleanup!

 This section is in need of cleanup!

 This section is in need of cleanup!

JTAG PinoutsEdit

 This section is in need of cleanup!

JTAG RecoveryEdit

 This section is in need JTAG Recovery Instructions!

Serial PinoutsEdit

 This section is in need of cleanup!

Hyper terminal Setup in Windows XPEdit

In Windows XP, Click Start Button - All Programs - Accessories -
   Communication - HyperTerminal
Enter a name for the connection, Click ok
Choose com port you adapter is plugged into, Click ok
Set:
 Bits per second = 115200
 Data Bits = 8
 Parity = none
 Stop bits = 1
 Flow control = none
Click ok
Click File - Save As, and select a place to save it to so you
             don't have to enter the settings again.

Putty Setup in Windows XPEdit

After installing putty, run it
 Serial line = The COM port your using for serial (ie. COM3)
 Speed = 115200
Click on Serial under Connection
 Serial line to connect to = same as above (Serial line)
 Speed (baud) = 115200
 Data bits = 8
 Stop bits = 1
 Parity = None
 Flow control = None
Click Session
 Enter a name for your connection under saved sessions
Click Save
Click Open

Serial RecoveryEdit
